Lamps eco SINO (DC)





1. Seria  SDCM

mini fluorescent lamps fit most luminaries, such as low-profile wall and ceiling luminaries, floor-standing lights and desktop lights. suitable for all rooms, especially where continuous economical lighting is needed


5W 7W
9W 11W



     Technical Features

  • Pre-heat Circuit Installed

  • Polarity Protection

  • Rated Voltage: 12V (10.5V-15V) or 24V (18V-28)

  • Lowest Stating Voltage: 8V or 16V (Pre-Heat Circuit NOT Installed)

  • Rated Wattage: 15W, 20W, 25W (+5%/-10%)

  • Operation Temperature: -10C-+50C

  • Lamp Base: B22d/E26/E27

  • Tested Life Span: 6,000hrs

  • Color Rendering Index (Ra): >80

  • Color Temperature: 2700K/4200K/6200K

  • Not Dimmable

  • Fuse Installed (Optional)





Produc Code Model Power
(watts)
Power luminus
(lm)
L x D
(mm)
LPL00041 SDC-M3 3 W 150 115x54
LPL00042 SDC-M5 5 W 200 115x54
LPL00043 SDC-M7 7 W 350 125x54
LPL00044 SDC-M9 9 W 450 135x54
LPL00045 SDC-M11 11 W 600 145x54
LPL00046 SDC-M13 13 W 720 145x54




  >>>back to top



2.Seria SDCB

The bulb-shaped glass cover of  SLB series energy saving lamp makes light output soft. The SLB undetachable structure shortens the bulb length and makes it possible to be used in place of traditional incandescent light bulbs. It is especially fit for place where incandescent light bulbs are previously installed and needs continuous economical lighting

5W & 7W

9W & 11W





     Technical Features

  • Pre-heat Circuit Installed

  • Polarity Protection

  • Rated Voltage: 12V (10.5V-15V) or 24V (18V-28)

  • Lowest Stating Voltage: 8V or 16V (Pre-Heat Circuit NOT Installed)

  • Rated Wattage: 15W, 20W, 25W (+5%/-10%)

  • Operation Temperature: -10C-+50C

  • Lamp Base: B22d/E26/E27

  • Tested Life Span: 6,000hrs

  • Color Rendering Index (Ra): >80

  • Color Temperature: 2700K/4200K/6200K

  • Not Dimmable

  • Fuse Installed (Optional)

Produc Code Model Power (watts) Power luminus (lm) L xD  (mm)
LPL00047 SDC-B5 5 W 180 115x60
LPL00048 SDC-B7 7 W 280 122x60
LPL00049 SDC-B9 9 W 350 132x60
LPL00050 SDC-B11 11 W 450 142x66





 >>>back to top



3.  Series SDCT

compact fluorescent lamps fit most luminaries, such as restaurants, hotels, foyers, corridors, surgeries and offices. Suitable for all rooms, especially where continuous economical lighting is needed.



15W & 20W

23W & 25W





     Technical Features

  • Pre-heat Circuit Installed

  • Polarity Protection

  • Rated Voltage: 12V (10.5V-15V) or 24V (18V-28)

  • Lowest Stating Voltage: 8V or 16V (Pre-Heat Circuit NOT Installed)

  • Rated Wattage: 15W, 20W, 25W (+5%/-10%)

  • Operation Temperature: -10C-+50C

  • Lamp Base: B22d/E26/E27

  • Tested Life Span: 6,000hrs

  • Color Rendering Index (Ra): >80

  • Color Temperature: 2700K/4200K/6200K

  • Not Dimmable

  • Fuse Installed (Optional)

Produc Code

Model Power (watts) Power luminus (lm) L x D  (mm)
LPL00051 SDC-T15  15 W 850 140x52
LPL00052 SDC-T20  20 W 1150 155x52
LPL00053 SDC-T23  23 W 1250 165x52
LPL00054 SDC-T25  25 W 1400 170x52







  >>>back to top







 4. Series SDCS

 SDC-S series compact fluorescent lamps fit most luminaries, such as restaurants, hotels, foyers, corridors, surgeries and offices. Suitable for all rooms, especially where continuous economical lighting is needed. Old version of this series is an older design with a longer length. The new version  SLSN is designed in more compact size.







15W, 20W & 25W





      Technical Features

  • Pre-heat Circuit Installed

  • Polarity Protection

  • Rated Voltage: 12V (10.5V-15V) or 24V (18V-28)

  • Lowest Stating Voltage: 8V or 16V (Pre-Heat Circuit NOT Installed)

  • Rated Wattage: 15W, 20W, 25W (+5%/-10%)

  • Operation Temperature: -10C-+50C

  • Lamp Base: B22d/E26/E27

  • Tested Life Span: 6,000hrs

  • Color Rendering Index (Ra): >80

  • Color Temperature: 2700K/4200K/6200K

  • Not Dimmable

  • Fuse Installed (Optional)

Specifications:
Produc Code Model Power  (watts) Power luminus  (lm) L  x D (mm)
LPL00055 SDC-S 15 15 W 850 122x60
LPL00056 SDC-S 20 20 W 1150 132x60
LPL00057 SDC-S 25 25 W 1400 145x60





  >>>back to top
