Micro-Hidro
Turbine TURGO EV
(500W
-10KW)
|
|
Micro-hydro
turbines are the most cost effective products to produce electrical
energy.
|
|
|
|
|
|
|
|
|
|
1. Hydro-Turbine
EV_LPE -DC |
|
|
|
|
|
|
|
|
|
 |
Tip
: |
Turgo |
| Nominal
Power (W) : |
500 |
| U
Nom (V) : |
12/24/48VDC |
| Head
min (m) |
10 |
| Head
max (m) |
200 |
| Flow
min (l/s) |
0,3 |
| Flow
max (l/s) |
10 |
| Runner
Diam. ( mm) |
100 |
| regulator
included |
Yes |
| diversion
load included |
Yes |
| Generator
type: |
Induction Hi
Eff. 230V 3
Phase |
| Water
to Wire Efficiency: |
Max
55% Min.
35% |
| Cod
Produs: |
LPH00061 |
Model: |
EV-LPE
500-100 DC |
|
|
|
Tip : |
Turgo |
| Nominal
Power (W) : |
1000 |
| U Nom
(V) : |
24/48/ VDC |
| Head
min (m) |
20 |
| Head
max (m) |
200 |
| Flow
min (l/s) |
1 |
| Flow
max (l/s) |
20 |
| Runner Diam. ( mm) |
100/150 |
| regulator included |
Yes |
| diversion load
included |
Yes |
| Generator type: |
Induction Hi Eff.
230V 3 Phase |
| Water to Wire
Efficiency: |
Max.60% Min. 45% |
| Cod
Produs: |
LPH00062 |
Model: |
EV-LPE
1000-150-DC |
|
|
|
Tip : |
Turgo |
| Nominal
Power (W) : |
2000 |
| U Nom
(V) : |
24/48 VDC |
| Head
min (m) |
20 |
| Head
max (m) |
200 |
| Flow
min (l/s) |
2 |
| Flow
max (l/s) |
50 |
| Runner Diam. ( mm) |
150/200 |
| regulator included |
Yes |
| diversion load
included |
Yes |
| Generator type: |
Induction Hi Eff.
230V 3 Phase |
| Water to Wire
Efficiency: |
Max.60% Min. 45% |
| Cod
Produs: |
LPH00063 |
Model: |
EV-LPE
2000-150-DC |
|
|
|
|
|
|
|
|
|
|
2. Hydro-Turbine EV_LPE AC
|
|
|
|
|
|
|
|
|
|
|
 |
Tip
: |
Turgo |
| Nominal
Power (W) : |
1000 |
| U
Nom (V) : |
220V
AC 1 PH |
| Head
min (m) |
20 |
| Head
max (m) |
150 |
| Flow
min (l/s) |
1 |
| Flow
max (l/s) |
20 |
| Runner
Diam. ( mm) |
100/150 |
| 3
channel IGC included |
Yes |
| diversion
load included |
Yes |
| Generator
type: |
Induction Hi Eff.
230V 3 Phase |
| Water
to Wire Efficiency: |
Max 65% Min 50% |
| Cod
Produs: |
LPH00064 |
Model: |
EV-LPE
1000-150-AC |
|
|
Tip
: |
Turgo |
| Nominal
Power (W) : |
2000 |
| U
Nom (V) : |
220V AC 1 PH |
| Head
min (m) |
20 |
| Head
max (m) |
200 |
| Flow
min (l/s) |
2 |
| Flow
max (l/s) |
50 |
| Runner Diam.
( mm) |
150/200 |
| 3 channel
IGC included |
Yes |
| diversion
load included |
Yes |
| Generator
type: |
Induction Hi Eff.
230V 3 Phase |
| Water to
Wire Efficiency: |
Max 65% Min 50% |
| Cod
Produs: |
LPH00065 |
Model: |
EV-LPE
2000-150-AC |
|
|
Tip
: |
Turgo |
| Nominal
Power (W) : |
3000 |
| U
Nom (V) : |
220V
AC 1PH |
| Head
min (m) |
20 |
| Head
max (m) |
200 |
| Flow
min (l/s) |
2 |
| Flow
max (l/s) |
50 |
| Runner
Diam. ( mm) |
150/200 |
| 3
channel IGC included |
Yes |
| diversion
load included |
Yes |
| Generator
type: |
Induction Hi Eff.
230V 3 Phase |
| Water
to Wire Efficiency: |
Max 70% Min 60% |
| Syncronus
Gen |
optional |
| ELC |
optional |
| 3
Phase version |
optional |
| Cod
Produs: |
LPH00066 |
Model: |
EV-LPE
3000-150-AC |
|
|
Tip
: |
Turgo |
| Nominal
Power (W) : |
5000 |
| U
Nom (V) : |
220/380V
AC 3PH |
| Head
min (m) |
20 |
| Head
max (m) |
250 |
| Flow
min (l/s) |
4 |
| Flow
max (l/s) |
100 |
| Runner
Diam. ( mm) |
200-300 |
| 9
Channel IGC included |
Yes |
| diversion
load included |
Yes |
| Generator
type: |
Induction Hi Eff. 220/380V 3PH |
| Water
to Wire Efficiency: |
Max 70% Min 60% |
| Syncronus
Gen |
optional |
| ELC |
optional |
| Cod
Produs: |
LPH00067 |
Model: |
EV-LPE
5000-200-AC |
|
|
|
|
Tip
: |
Turgo |
| Nominal
Power (W) : |
10000 |
| U
Nom (V) : |
220VAC/380VAC |
| Head
min (m) |
20 |
| Head
max (m) |
250 |
| Flow
min (l/s) |
4 |
| Flow
max (l/s) |
200 |
| Runner
Diam. ( mm) |
200/300 |
| 9
Channel IGC included |
Yes |
| diversion
load included |
Yes |
| Generator
type: |
Induction Hi Eff. 220/380V 3PH |
| Water
to Wire Efficiency: |
Max. 75% Min. 65% |
| Syncronus
Gen |
optional |
| ELC |
optional |
| Cod
Produs: |
LPH00068 |
Model: |
EV-LPE
10000-200-AC |
|
|
|
|
 |
|
|
|
|
|
|
|
| |
|
|
|
|
|
