Inverters LATRONICS - DC/AC







1. Series   - LS 400





Model LS-412 LS-524 LS-548
Product Code LPI00072 LPI00073 LPI00074
Nominal Battery Voltage 12 V 24 V 48 V
Continuous Power 400 W 500 W 500 W
½ Hour Rating 450 W 600 W 600 W
Surge Rating (5 seconds) 1400 W 2000 W 2000 W
Input Voltage Range 10.5-17 V 21-34 V 42-68 V
Instantaneous Shutdown 9 V 18 V 36 V
Standby Current 22 mA 18 mA 17 mA
Inverter ON – no load 0.42 A 0.31 A 0.18 A
Peak Efficiency 90% 92% 92%
Weight 4.5 Kg 4.7 Kg 4.7 Kg

Dimensions 260mm L x 160mm W x 100mm H
Output Voltage 240 V (+/- 4%)
Output Waveform True Sinewave
Total Harmonic Distortion < 4%
Output Frequency 50Hz  (+/- 0.1%)
Power Factor All Conditions
Operating Temperatures -10deg to +50deg
Auto Start Sensitivity 0 - 20 W adjustable
Input/Output Isolation 3500 V
Protection Circuitry Overtemperature/Overload/Short Circuit/Battery Undervoltage/Battery Overvoltage
Battery Leads 1.0m Long with 10mm Mounting Lug
DC Isolation Thermal/Magnetic Circuit Breaker
Output Wiring Single GPO
Chassis Powder Coated 2mm Aluminium
Standards AS2279, AS3000, AS3001, EN55014, & C-Tick
Warranty 2 Years Parts and Labour





  >>>back to top



2.Series - LS 1000





Inverter Model LS-812 LS-1024 LS-1048
Product Code LPI00075 LPI00076 LPI00077
Nominal DC Voltage 12 V 24 V 48 V
Continuous Power 800 W 1000 W 1000 W
½ Hour Rating 1000 W 1400 W 1400 W
Surge Rating (5 seconds) 2800 W 3500 W 3500 W
Input Voltage Range 10.5-17 V 21-34 V 42-68 V
Instantaneous Shutdown 9 V 18 V 36 V
Standby Current 37 mA 28 mA 22 mA
Inverter ON – no load 0.45 A 0.25 A 0.19 A
Peak Efficiency 91% 92% 94%
Weight 11 Kg 11 Kg 11 Kg
Dimensions 330 mm L x 296 mm W x 150 mm H
Output Voltage 240Vac +/- 4%
Output Waveform True Sinewave
Total Harmonic Distortion <4%
Output Frequency 50Hz +/- 0.1%
Power Factor All Conditions
Operating Temperature -10° C to +50° C
Autostart Sensitivity 0 – 20 W adjustable
Input/Output Isolation 3500V
Protection Circuitry Overtemperature - Overload/Short Circuit - Battery Undervoltage - Battery Overvoltage
Battery Leads 1.5m long with 10mm mounting lugs
DC Isolation Thermal/Magnetic Circuit Breaker
Output Wiring Single power outlet & junction box
Chassis Powder coated 3mm Aluminium
Standards AS2279, AS3000, AS3001, EN55014, & C-Tick
Warranty 2 Years Parts and Labour



 >>>back to top



3. Series  - LS 1500



Inverter Model LS-1212 LS-1524 LS-1548
Product Code LPI00078 LPI00079 LPI00080
Nominal DC Voltage 12 V 24 V 48 V
Continuous Power 1200 W 1500 W 1500 W
½ Hour Rating 1500 W 2100 W 2100 W
Surge Rating (5 seconds) 4000 W 5000 W 5000 W
Input Voltage Range 10.5-17 V 21-34 V 42-68 V
Instantaneous Shutdown 9 V 18 V 36 V
Standby Current 42 mA 30 mA 24 mA
Inverter ON – no load 0.67 A 0.32 A 0.26 A
Peak Efficiency 91% 94% 94%
Weight 14 Kg 14 Kg 14 Kg
Dimensions 330 mm L x 296 mm W x 150 mm H
Output Voltage 240Vac +/- 4%
Output Waveform True Sinewave
Total Harmonic Distortion <4%
Output Frequency 50Hz +/- 0.1%
Power Factor All Conditions
Operating Temperature -10° C to +50° C
Autostart Sensitivity 0 – 20 W adjustable
Input/Output Isolation 3500V
Protection Circuitry Overtemperature - Overload/Short Circuit - Battery Undervoltage - Battery Overvoltage
Battery Leads 1.5m long with 10mm mounting lugs
DC Isolation Thermal/Magnetic Circuit Breaker
Output Wiring Single power outlet & junction box
Chassis Powder coated 3mm Aluminium
Standards AS2279, AS3000, AS3001, EN55014, & C-Tick
Warranty 2 Years Parts and Labour



  >>>back to top







 4. Series - LS 2000, 3000, 5000







Inverter Model LS-2012 LS-2324 LS-3024 LS-3548 LS-5548
Product Code LPI00081 LPI00082 LPI00084 LPI00085 LPI00086
Nominal DC Voltage 12V 24V 24V 48V 48V
Continuous Power 2000W 2300W 3000W 3500W 5500W
½ Hour Rating 2200W 2800W 3700W 4100W 6500W
Surge Rating (5 secs) 5500W 7000W 9000W 10500W 15000W
Input Voltage Range 10.5-17V 21-34V 21-34V 42-68V 42-68V
Instantaneous Shutdown 9V 18V 18V 36V 36V
Standby Current 75mA 45mA 50mA 40mA 60mA
Inverter ON - no load 1.1A 0.51A 0.6A 0.33A 0.49A
Peak Efficiency 90% 94% 93% 94% 95%
Weight 22Kg 22Kg 24Kg 24Kg 33Kg
Dimensions 370 mm [L] x 386mm [W] x 180 mm [H] 475 x 458 x 187
Output Voltage 240Vac +/- 4%
Output Frequency 50Hz +/- 0.1%
Output Waveform True Sinewave
THD <4%
Power Factor All Conditions
Autostart Sensitivity 0 – 20 W adjustable
Operating Temperature -10°C to +50°C
DC to AC Isolation 3500V
Protection Circuitry Overtemperature, Overload/Short Circuit, Battery Undervoltage/Overvoltage
Battery Leads 1.5 Metres long with 10mm mounting lugs
AC Output Wiring 3 Terminal Hardwire Junction Box, labelled “AC Output”
AC Input Wiring 3 Terminal Hardwire Junction Box, labelled “AC Input”
Chassis Powder Coated 3mm Aluminium P.C.4mm Alum.
Warranty 3 Years Parts and Labour
Standards AS2279, AS3000, AS3100, EN55014, & C-Tick.
Ratings Specifications @ 25°C ambient nominal battery voltage & unity power factor
